2026 FARM KING 2400

General

Year

2026

Manufacturer

FARM KING

Category

Miscellaneous Other Equipment

Price

Call for price

Technical Data

Model

2400 - Engine or PTO Drive

Frame

All welded tubular steel construction

In Frame Counterweight Box

15" x 15" x 25" - 3.2 cu. ft. (92L)

Wheel Track Width

69" (1750 mm)

Wheel Rims

15" (381 mm) (6.70 x 15 4-ply bias tires optional)

Wheel Bearings

Tapered Roller

Mast

12" (305 mm) wide track

Hammer Weight

310 lb (141 kg) empty, up to 700 lb (318 kg) ballasted

Impact at Full Stroke

100,000 lb (45,360 kg)*

Maximum Hammer Height

Standard lift 105" (2.67 m), 128" (3.25 m) with optional mast extension

Minimum Hammer Height

43" (1090 mm), 66" (1676 mm) with optional mast extension

Maximum Hammer Stroke

62" (1570 mm)

In & Out Hammer Slide

16" (410 mm)

Hammer Tilt, From Vertical

Fore 20° / Aft 15°, Side Tilt: Left 40° / Right 22°

Basic Shipping Weight

PTO: 1190 lb (540 kg), Engine: 1300 lb (590 kg)

*

Impact lb are based on an 8" diameter post driven into packed clay soil with non ballasted hammer. Impact increases proportionally with ballast in hammer.

Description
